Honda GX390 13HP Petrol Engine

Engine Type Air cooled 4 stroke OHV petrol engine, 25° inclined cylinder, horizontal shaft
Cylinder Sleeve Type Cast Iron Sleeve
Bore x Stroke 88 x 64mm
Displacement 389 cm3
Compression 8.0 : 1
Net Power 8.2 Kw (11 HP) / 3600 rpm)
Cont. rated power 6.0 kW (8.0 HP) / 3000 rpm
6.6 kW (8.9 HP) / 3600 rpm
Max net torque 25.1 Nm / 2.56 Kgm / 2500 rpm
Ignition System Transistorised
Starting System Recoil (Electric Start Optional)
Fuel tank Capacity 6.10 l
Fuel cons. at rated power 3.7 L/hr – 3600 rpm
Engine Oil Capacity 1.1 l
Dimensions
(L x W x H)
405 x 450 x 447 mm
Dry Weight 31 kg
