Description
| Features | Benefits |
|---|---|
| TransportGuard™ System | Simultaneous fuel/ignition shut-off protects the engine from oil/fuel dilution during transport |
| Overhead Valve Design | Runs cooler and cleaner delivering more power, longer engine life and improved fuel economy |
| Commercial-style Carburertor | Additional fuel passages ensure reliable starting and smooth running operation at a wide range loads |
| Large, Efficient Sediment Filter | Sediment is collected in a large, clear bowl and is drained using a convenient tool-free valve |
| All-metal Fuel Tank | Reduces emissions and is mounted directly to the engine block to enhance durability |
| Engine Warranty | Two year commercial engine warranty for all applications |
| Lubrication | |
| Motorsports Rod/Dipper Design | Efficiently improves oil flow throughout the engine; assures maximum protection of internal components |
| Oil Sensor | Automatically shuts down the engine in low oil situations to safeguard investment |
| Splash Lubrication System | Delivers superior lubrication to the engine to ensure long life and reliability |
| Mechanical | |
| High-mounted Canister-style Air Cleaner | 22% more filter area than the competition; water-repellent filter with innovative triple seal design dramatically decreases dirt, dust and debris intake |
| Magnetron® Electronic Ignition | Quick dependable starts with no maintenance required |
| Larger Ignition Coil | Assures fast, easy starts |
| Innovative Combustion Chamber | Improves air and fuel flow, resulting in a cleaner burn, reduced emissions and increased horsepower |
| Cylinder Head and Head Gasket | Increases power, stability and torque retention |
| Forged Crankshaft | Incorporates heat-treated ball bearings to minimize friction and heat build-up |
| Engine Dimensions | |
|---|---|
| Dimensions (LxWxH) | 12.48 in (317 mm) x 16.42 in (417 mm) x 15.98 in (406 mm) |
| Weight | 57.1 lbs (25.9 kg) |
| Fuel Tank Capacity | 3.7 L |
| Oil Capacity | 28oz (0.8L) |
| Engine Displacement | 305 cc (18.61 cu in) |
| Engine Specifications | |
|---|---|
| Gross Horsepower* | 9 Gross HP |
| Engine Displacement | 305 cc (18.61 cu in) |
| Number of Cylinders | One |
| Engine Configuration | Horizontal |
| Bore | 3.12 in (79 mm) |
| Stroke | 2.44 in (62 mm) |
| Compression Ratio | 8.1:1 |
| Ignition System | Magnetron® |
| Lubrication System | Splash |
| Carburetor | Single Barrel Float Feed |
| Engine Cooling | Air |
| Engine Fuel | Gasoline |
| Governor | Mechanical |
| PTO (Standard) | 1″ SAE Keyway |
| Cylinder Block | Aluminum with Cast Iron Sleeve |
| Crankshaft | Forged |
| PTO Shaft Rotation | Counterclockwise from PTO side |
| Starter | Rewind or Electric |
Additional information
| brand | VANGUARD |
|---|
